Engineering Guide Based on Sand, Viscosity, Depth & Reservoir Performance
In modern oilfield production, artificial lift system selection directly determines production stability, workover frequency, and lifecycle operating cost.
A mismatch between pump type and reservoir conditions can lead to:
Frequent pump failure
Rod or valve wear
Gas lock issues
Sand abrasion damage
Reduced lifting efficiency
At Dongsheng Oil Machinery Co., Ltd., we specialize in designing and manufacturing sucker rod pumps, tubing pumps, and screw pump systems for complex oilfield environments, including sandy wells, high-viscosity crude, and deep reservoirs.
This guide is based on real engineering selection logic used in field applications.
1. Key Engineering Factors for Pump Selection
Artificial lift selection should always be based on reservoir diagnostics rather than pump preference.
1.1 Reservoir Fluid Characteristics
Oil viscosity (light / medium / heavy / extra-heavy oil)
Sand content (abrasive wear risk level)
Gas-to-oil ratio (gas locking probability)
Water cut (corrosion acceleration factor)
Wax/paraffin deposition tendency
1.2 Wellbore Conditions
Well depth (shallow / medium / deep / ultra-deep)
Pump setting depth
Dynamic fluid level stability
Production decline rate
1.3 Environmental Conditions
H₂S / CO₂ corrosion presence
Chloride ion concentration (offshore/high-salinity fields)
Formation temperature (affects elastomer & seal life)
2. Main Artificial Lift Pump Types
2.1 Tubing Pump (TH Type)
TH Tubing Pump
Engineering Role:
Designed for deep wells and high-production stable reservoirs.
Technical Characteristics:
Installed as part of the tubing string
High volumetric efficiency
Suitable for high-load capacity wells
Performance Range (Typical Industry Use):
Well depth: medium to ultra-deep wells
Flow rate: medium to high production
Maintenance cycle: long (requires tubing pull)
Advantages:
High structural strength
Excellent for deep reservoir lifting
Stable long-term operation
Limitation:
Workover requires full tubing retrieval → higher intervention cost
2 .2 Insert Rod Pump (RHA / RWB Type)
InsertRodPump
Engineering Role:
Best suited for unstable wells requiring frequent maintenance flexibility.
Technical Characteristics:
The pump can be retrieved via the rod string
Modular maintenance design
Quick replacement capability
Advantages:
Reduced workover time
Ideal for waxy or sand-prone wells
Flexible field operation
Limitations:
Slightly lower efficiency than tubing pump in deep wells
Typical Use Cases:
Medium and shallow wells
Variable production wells
High intervention frequency wells
2.3 Screw Pump (PCP System)
PCPProgressiveCavityPump
Engineering Role:
Designed for heavy oil, high viscosity, and sand production wells.
Technical Characteristics:
Continuous displacement pump
No valve system (reduces clogging risk)
Elastomer stator system
Advantages:
Excellent for high-viscosity crude oil
Strong sand-handling capability
Smooth continuous flow (low pulsation)
Limitations:
Elastomer wear under high temperature or chemical attack
Requires periodic stator replacement
Field Example:
In heavy oil reservoirs with sand content above 1–3%, PCP systems often extend maintenance cycles compared with valve-based pumps.
2.4 Electric Submersible Pump (ESP)
ESPElectricSubmersiblePump
Engineering Role:
Best for high-output, low-sand, light oil reservoirs.
Technical Characteristics:
Multi-stage centrifugal system
High flow rate capacity
Requires stable power supply
Advantages:
Very high production capacity
Suitable for deep wells
High efficiency in clean fluids
Limitations:
Sensitive to sand erosion
Gas interference reduces efficiency
3. Field-Based Pump Selection Logic
Scenario A: High Sand Production Wells
Recommended:
Screw Pump (PCP)
Reinforced Insert Rod Pump
Engineering Reason:
Sand particles accelerate valve erosion in tubing/rod pumps. PCPs reduce mechanical impact due to continuous displacement.
Scenario B: Deep Wells with Stable Production
Recommended:
Tubing Pump (TH Type)
Reason:
High mechanical strength required for deep well load conditions.
Scenario C: Waxing or Unstable Wells (Frequent Failures)
Recommended:
Insert Rod Pump
Reason:
Fast retrieval reduces downtime and workover cost.
Scenario D: High Production Clean Oil Wells
Recommended:
ESP System
Reason:
Centrifugal systems provide maximum lifting efficiency under clean conditions.
Scenario E: Heavy Oil + High Viscosity + Sand
Recommended:
Screw Pump (PCP System)
Reason:
Best performance in viscous and abrasive environments.
4. Real Field Engineering Case
Case: High-Sand Heavy Oil Well Optimization
Initial system: conventional rod pump
Issue: frequent valve failure every 30–45 days
Sand content: ~2.5%
Oil viscosity: high
Optimization:
Replaced with PCP system
Result:
Maintenance interval increased by ~2.5×
Stable production restored
Reduced workover frequency
This type of condition-driven optimization is the core principle of artificial lift design.
5. Industry Standards Reference
Artificial lift system design typically aligns with:
API RP 11AX (Sucker Rod Pumping Systems)
API Spec 11E (Pump standards)
ISO oilfield equipment corrosion resistance guidelines
6. Frequently Asked Questions
Q1: Which pump is best for sandy oil wells?
Screw pumps (PCP) or reinforced rod pumps are preferred due to better abrasion resistance.
Q2: What is the main difference between tubing pump and insert rod pump?
Tubing pumps offer higher capacity, while insert rod pumps provide easier maintenance.
Q3: Can ESP work in high gas wells?
ESP performance decreases significantly in high gas-to-oil ratio wells due to gas locking.
Q4: What pump is best for heavy oil production?
PCP systems are most effective for high-viscosity crude oil.
Q5: How to reduce pump failure rate in oilfields?
Proper matching of pump type with reservoir conditions is the key factor.
7. Why Dongsheng Oil Machinery?
Dongsheng Oil Machinery Co., Ltd. focuses on artificial lift system engineering for global oilfields.
We provide:
Tubing pumps (TH series)
Insert rod pumps (RHA / RWB series)
Screw pump systems (PCP solutions)
Custom OEM design for complex wells
Our engineering team supports:
Reservoir-based pump selection
Anti-sand & anti-corrosion design
High-temperature material customization
Full lifecycle technical support
Artificial lift selection is not a product choice—it is a reservoir engineering decision.
Correct pump selection can:
Improve production stability
Reduce workover frequency
Lower total lifecycle cost
If you want, Dongsheng Oil Machinery can providewell-specific pump selection recommendations based on your reservoir data.
