Our Tieling Dongsheng Petroleum Machinery Co., Ltd. it is a company specializing in the production and manufacture of petroleum extraction machinery and parts. Our API tubing pump is produced in Liaoning, China, with an annual supply capacity of 20,000 pieces and a delivery time of only 8-10 weeks. It can provide stable and reliable solutions for oilfield customers around the world.
Our API Itubing pump adopts an integrated thick cylinder design to achieve precise matching of the plunger after precision grinding, and the large inner diameter structure increases the fluid displacement of each stroke. At the same time, the heavy-duty construction of the API tubing pump we produce and design can withstand high loads, corrosion and extreme wear. Our modular wearing parts design eliminates the need for large-scale hoisting for on-site maintenance, and allows you to manually disassemble and assemble directly at the wellhead. Our API tubing pump parts are highly interchangeable, can be applied to various specifications of tubing and sucker rod systems, flexible and convenient assembly, and can reduce your maintenance costs to a certain extent.
Our CYB-[d]TL(F1) series API tubing pump has a compact structure, stable performance, good carrying capacity and convenient maintenance, and can be widely used in medium and deep wells, sand-bearing wells and high-frequency operating wells. The wear-resistant and corrosion-resistant version of our API tubing pump uses a high-performance composite coating and special alloy materials, and its service life is 1-3 times longer than that of traditional models, which can better reduce the frequency of underground operations and comprehensive operating costs. The pump barrel of our API tubing pump is made of high-strength steel with a surface hardness of more than HRC60, which effectively prevents cracks and deformation; The surface cladding technology forms a 0.2mm+ nickel-based coating, which effectively improves the self-lubricating, high temperature resistance and corrosion resistance of our API tubing pump.
The core structure of our API tubing pump includes a sucker rod, an up-gauge valve, a plunger, a barrel type and an inflow valve. We all adopt a modular design to ensure efficient operation. The technical parameters cover a variety of pump hole sizes (such as 32mm to 93mm), plunger length 0.6~1.2 meters, barrel length 2.1~7.5 meters, and support different tubing interface standards. Our API tubing pump is suitable for high-wear wells (sandstone formations), oil fields with slight corrosion but high life requirements, remote oil wells, and economically cost-sensitive well sites.
Why should you choose us Tieling Dongsheng Petroleum Machinery Co., Ltd. what about the API tubing pump? Because each of our API tubing pump components has undergone triple quality inspection, our codes can be traced for easy after-sales tracking, and we support customized services to meet your multi-well needs. With its own reliability and long life, our API tubing pump hopes to be your choice for oilfield operations. If you have any other needs, you can always consult and understand with us, and we will be at your service at any time!
